Mini Cistern Stop - Brushed Copper

SKU: 12308

in stock


Mini Cistern Stop - Brushed Copper

SKU: 12308

in stock


$65.90
Add to Cart
Also Bought With
Chevron-Down

Product Details

The Mini Cistern Stop provides a modern take on the often-overlooked bathroom component.

Its streamlined, minimalistic design adds the perfect final touch to your bathroom fixtures.

Constructed from solid brass, the Mini Cistern Stop allows your contemporary vision to tie in cohesively.

Features:
– Utilises innovative ceramic disc technology.
– Handle is made of solid brass to assure longevity.
– 1/2 Inch thread outlet connection.
– Quarter turn handle dial.
– Solid brass construction.

Dimensions:
Projection: 77mm
Handle length: 38mm
Backplate diameter: 49mm

Warranty:
25 years structural warranty
10 years cartridge warranty
5 years finish/coating warranty

Product Info

  • Features
  • Specifications
  • Warranty
  • Environment
  • Downloads
Solid Brass
PVD (Physical Vapour Deposition)
Universal Fitting
SKU 12308
Weight 0.28kg
Brand ABI-International
DIMENSIONS (MM) Projection: 77, Handle length: 38, Backplate diameter: 49
MATERIAL Solid Brass
FINISH/COATING ABI's Heat Shield – Industrial Grade PVD Electro Colouring System
Outlet Connection 1/2 Inch thread
Handle Dial Quarter Turn
Spindle Type Ceramic Disc
ETA

Specification guides can be found under the Downloads tab.

PRODUCT DESCRIPTION RESIDENTIAL WARRANTY NON-RESIDENTIAL WARRANTY OUTDOOR WARRANTY
Name & Finish SKU Structure Finish Cartridge Other Structure Finish Cartridge Other Structure Finish Cartridge Other
Mini Cistern Stop - Brushed Copper 12308 25 5 7 2 10 1 5 1 - - - -
Bim Files
View Product Download
View Library Download

Product FAQs


What is a Mini Cistern Stop?

A single valve allowing you to isolate the water for any servicing requirements. A Mini Cistern Stop creates a "block off" point between your toilet and your main water supply


What is the connection size?

1/2 female inlet to 1/2 male outlet connection.


Do I need one?

You will require one if your cistern is not concealed.


Does this include hoses?

No.


Can I use a Mini Cistern Stop to turn off my water for the shower/basin?

Our Mini Cistern Stops can also be used for a basin or kitchen isolation valve. Our cistern stop acts as an isolation valve with a 1/2 connection and 1/2 outlet
