Sensor Wall-Mounted Spout - Matte Black
SKU: 15862
T41823 (V)| WELS: 6 Star | Litres / min: 5.5
Free Delivery on Orders Over £500!
Sensor Wall-Mounted Spout - Matte Black
SKU: 15862
T41823 (V)| WELS: 6 Star | Litres / min: 5.5
Free Delivery on Orders Over £500!
Colour: Matte Black
Product Details
Our Sensor Wall-Mounted Spout is a moulded and hollowed tapware fixture, which guarantees long-lasting durability and provides smooth water flow thanks to its soft curvature. Contactless tapware is a safe, convenient, and economical solution for domestic and commercial spaces.
Constructed from 304 stainless steel, this spout combines a beautiful streamlined design with innovative technology. It features an infrared sensor that instantly stops when you remove your hands to experience exceptional water-saving capabilities.
Please Note:
– A mixer will not need to be purchased with this product.
Features:
– Smart infrared sensor-operated spout function for superior water-saving benefits.
– 304 stainless steel construction offers durability for indoor and commercial use.
– AC Power Adapter included for a maintenance-free power option.
Dimensions:
– Height: 96mm
– Length: 222mm
– Backplate Diameter: 60mm
– Spout Reach: 208mm (from the centre of the base to the centre of the spout)
– Spout Body Diameter: 28mm
Product Features
304 Stainless Steel
.svg){kind=icon}
PVD (Physical Vapour Deposition)
Water Saving
Material
Construction
304 Stainless Steel
Finish/Coating
(PVD) Matte Black - ABI’s Heat Shield – Industrial Grade Electro Colouring System (Physical Vapour Deposition)
*We implement strict quality procedures to minimise colour variations, however we acknowledge that there may be minor differences between batches. We encourage you to check over your items once received to ensure that you are satisfied with the finish. Should you receive anything of concern, our team is here to help! For more information on our finish quality
For more information on our finish quality
Specifications
| SKU | 15862 |
| Weight | 1.725kg |
| Brand | ABI Interiors |
| Finish/Coating | (PVD) Matte Black - ABI’s Heat Shield – Industrial Grade Electro Colouring System (Physical Vapour Deposition) |
| Construction | 304 Stainless Steel |
| Dimensions (mm) | Height: 96mm Length: 222mm Backplate Diameter: 60mm Spout Reach: 208mm (from the centre of the base to the centre of the spout) Spout Body Diameter: 28mm |
| What's In The Box | 1 x Sensor Spout 1 x G1/2 Flexi 500mm 1 x Solenoid 1 x Battery Case 1 x Battery Case Bracket 1 x AC Adapter 1 x Back Plate Bracket 1 x Allen Key 2 x Back Plates 10 x Wall Plugs 10 x M4 Screws |
| ETA |
Specification guides can be found under the Downloads tab.
Downloads
Product Documents
| Sensor Wall-Mounted Spout - Specification |  |
| Sensor Wall-Mounted Spout - Scope of Use | |
Bim Files
| View Product |  |
| View Library | |
Matte Black
At ABI, we use the highest quality materials and colouring processes to ensure a durable and timeless finish that you will love for years to come. Like many other materials, the colour may appear differently from product to product due to lighting within the installation location and reflection on products with different surfaces (flat and curved).
While we do our best to ensure consistency between batches and use strict colour toning and matching quality procedures to lessen variations, we acknowledge that there may be minor variations between batches. We encourage you to check over your items once received to ensure that you are satisfied with the finish. Should you receive anything of concern, our team is here to help!
| PRODUCT DESCRIPTION | RESIDENTIAL WARRANTY | NON-RESIDENTIAL WARRANTY | OUTDOOR WARRANTY | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Name & Finish | SKU | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other |
| Sensor Wall-Mounted Spout - Matte Black | 15862 | 25 | 5 | 7 | 2 | 5 | 1 | 5 | 1 | - | - | - | - |
6
Water Rating
5.5
Litres Per Minute
T41823 (V)
Registration Number
Product FAQs
Is there an alternative power supply for the Sensor Spouts?
The AC Adapter as well as the four AA batteries can be used to power the Sensor Spouts. If there is a loss of power from the wall outlet, the adapter will automatically switch to battery power. When the batteries run low, the sensor window will begin to flash, indicating that it is time to replace them.
Can I adjust the temperature and flow of the Sensor Wall-Mounted Spout?
To enable any flow functionality, we recommend purchasing a Mini Cistern Stop.
The sensor line is connected to cold water. We recommend purchasing a mixing valve from your local plumbing supplier if you wish to adjust to your desired temperature. ABI does not sell this part.
How long will the batteries last for the Sensor Wall-Mounted Spout?
Four AA batteries will last approximately 1.5 years before a replacement is required. When the voltage of the batteries drops below 4.5, the sensor window will begin to flash, indicating it is time for their replacement.
How do you operate the Sensor Wall-Mounted Spout?
The spout is operated by an infrared sensor located at the tip of the spout. Place your hands directly under the spout tip to turn the water on. Water is only activated when hands are actively triggering the sensor. When your hands are removed, the water flow will instantly stop.
How does the infrared sensor work?
The infrared sensor works by emitting a light that is invisible to the human eye, which bounces off an object (e.g. your hand) and back to the receiver on the sensor. Having your hand or another object under the spout will continuously trigger the sensor, causing the solenoid to remain open and water to flow. The solenoid has been programmed to shut off immediately when the sensor is no longer triggered. As the water shutoff time is less than two seconds, this tap can have a 4.5-star WELS rating.
Can the sensor range be adjusted?
Yes, you can easily adjust the sensor function to suit your requirements. Please refer to the online specification sheet under the ‘Downloads’ tab on the corresponding product page.
What is the AC Adapter reach?
The AC Adapter has a reach of up to 1500mm.
